CSA Miniature Quarter-Turn Electric Actuator 16 Nm IP67 ISO 5211

  • CSA Miniature Quarter-Turn Electric Actuator 16 Nm IP67 ISO 5211
  • CSA Miniature Quarter-Turn Electric Actuator 16 Nm IP67 ISO 5211
Place of Origin WUHAN,CHINA
Brand Name DCL
Certification CE/ROHS/CSA/IP67
Model Number DCL-02B
Minimum Order Quantity 1pc
Packaging Details carton/pallet
Delivery Time 7 working days
Payment Terms D/P,T/T,Western Union,
Supply Ability 5000PCS/month
Product Details
Standard Time/Torque 15S/18Nm Optional Time/Torque 7S/9Nm 60S/18Nm
Total Weight 1.2KG Power Supply 24VAC/110VAC/220VAC
Motor Power 6W Ambient Temperature -25℃~+55℃ / -13°F~+131°F
Installation Angle 360° Protection Grade IP67 NEMA4/4X
Leave a Message
Product Description

CSA DCL-02 Miniature Quarter-Turn Electric Actuator 16 Nm IP67 ISO5211

Description

The DCL-02 is a miniature quarter-turn electric actuator for compatible ball valves, small butterfly valves and swinging-arm mechanisms. It provides adjustable 0–90° travel, standard output torque of 16 Nm and a 15-second operating time over 90°. Weighing approximately 1.2 kg, it is suitable for equipment packages and piping installations with limited space.

Internal cams and travel limit switches interrupt motor operation at the set positions. The Type B configuration provides passive contacts for fully open and fully closed position feedback, allowing an external control system to confirm valve status. An intermediate stopping position can also be specified. For T-port three-way ball valves, confirm the stopping angles, rotation direction and required flow paths before ordering.

ISO 5211 F03, F04 and F05 mounting interfaces are available with 9×9 mm or 11×11 mm drive squares. The permitted valve-stem height is no more than 16 mm. Selection should be based on actual valve torque and mounting dimensions rather than nominal valve size alone.

The actuator has an IP67 enclosure and a stated ambient-temperature range of -25°C to +55°C. Typical applications include HVAC, water treatment, building automation and general industrial equipment. Power-supply options include DC12V, DC24V, AC24V, AC110V and AC220V. Available switching, feedback and modulating functions depend on the selected voltage and control configuration.

Specification
Performance Parameters
Type DCL-02
Power DC24V DC12V AC24V AC110V AC220V
Motor Power 8W 8W 6W 6W 6W
Rated Current 0.7A 1.6A 1.3A 0.3A 0.15A
Standard Time/Torque 15S/16Nm
Optional Time/Torque 7S/9Nm 30S/25Nm
Available Control Circuit Type G,GEY Type G,GEY Type of A,B Type of A,B ,E ,
Total Weight 1.2kg
Insulating Resistance 100MΩ/250VDC 100MΩ/500VDC
Withstand Voltage Class 500VAC 1 minute 1500VAC 1 minute
Protection Class IP67
Installation Angle 360° at any angle
Electric Interface 7-core cable for connection
Ambient Temperature -25～+55℃
Fuse 3A 2A 3A 1A 1A
Features
  • Quarter turn operation
  • Two auxiliary limit switches to confirm valve position
  • Hard high pressure die cast aluminum housing with weather proof IP67 and NEMA 4X
  • Non-ventilated motor with high starting torque and small inertia force
  • All metal self-locking gear train, stays in last known position once power loss
  • Valve position indicator/flat indicator or convex indicator available
  • Manual override
  • Standard ISO5211 direct installation
  • CSA certified per UL 429 and CSA C22.2, CE mark
