AC24V 90° 15S/18Nm DN32 MiniatureElectric Actuator

  • AC24V 90° 15S/18Nm DN32 MiniatureElectric Actuator
Place of Origin WUHAN,CHINA
Brand Name DCL
Certification CE/ROHS/CSA/IP67
Model Number DCL-02
Minimum Order Quantity 1pc
Packaging Details carton/pallet
Delivery Time 7 working days
Payment Terms D/P,T/T,Western Union,MoneyGram
Supply Ability 5000PCS/month
Product Details
Power DC24V/AC24V/AC110V/AC220V Time/Torque 15S/18Nm
Optional Torque 7s/9Nm 60s/18Nm Protection Class IP67
Motor Power 8W/6W Ambient Temperature -25℃~+55℃
Medium Gas/Oil/Water/Other Material Of Seal Surface Soft Sealed
Rated Current 0.15A~1.3A Connection Form Flange
Leave a Message
Product Description
CSA AC24V 90° 15S/18Nm Ultra Small Electric Actuator
Description

DCL-02 Series: Versatile & Compact Electric Actuators

Engineered for seamless integration into diverse automated control systems, the DCL-02 Series is ideal for HVAC, fire protection, water treatment, and precision control loops regulating level, flow, and pressure. Its robust design also makes it a highly reliable choice for the chemical processing and food manufacturing industries.

Specifically optimized for small-bore automation, the DCL-02 is the perfect match for butterfly valves (≤ DN40) and ball valves (≤ DN32). Featuring an ultra-compact footprint, it excels in space-constrained environments and supports 360° omnidirectional mounting—delivering total installation flexibility with zero operational restrictions.

Product specification
Type DCL-02
Power DC24V AC24V AC110V AC220V
Motor Power 8W 6W 6W 6W
Rated Current 0.7A 1.3A 0.3A 0.15A
Standard Time/Torque 15S/18Nm
Optional Time/Torque 7S/9Nm   60S/18Nm
Turning Angle or turns 0～90°
Available Control Circuit Type G Type of A,B Type of A,B ,E ,
Total Weight 1.2kg
Insulating Resistance 100MΩ/250VDC 100MΩ/500VDC
Withstand Voltage Class 500VAC 1 minute 1500VAC 1 minute
Protection Class IP67
Installation Angle 360° at any angle
Electric Interface 7-core cable for connection
Ambient Temperature -25～+55℃
Fuse 2A 3A 1A 1A
Features
  • Subminiature in Volume(Smaller than a pop Can)
  • Super Torque (18Nm/15S)
  • Super Protection Performance (Full Aluminum alloy Casing)
  • Can choose open display device of adjustable convex type
  • IP68 water-proof cable connector
  • Mannual operation handle

AC24V 90° 15S/18Nm DN32 MiniatureElectric Actuator 0 AC24V 90° 15S/18Nm DN32 MiniatureElectric Actuator 1
