Burner Fuel DN400 Butterfly Valve DCL Smart Electric Actuator
Contact me for free samples and coupons.
Wechat: 0086 18588475571
If you have any concern, we provide 24-hour online help.x
|Standard Time/Torque||15S To 75S/18Nm To 2500Nm/160in.lbs To 22125in.lbs||Installation Angle||360°|
|Input Signal||4-20mA Or 2-10V / 1-5V Optional||Output Signal||4-20mA|
|Ambient Temperature||-25℃~+55℃ / -13°F~+131°F||Total Weight||2.5KG To 20KG|
|Motor Power||10W To 140W||Protection Grade||IP67 NEMA4/4X|
IP67 Smart Electric Actuator,
DCL Smart Electric Actuator,
DN400 Butterfly Valve Actuator
Burner fuel control used smart electric actuator/resistance to electromagnetic interference
- 90° turn with proportional to input control signal
- Modulating type for proportional control with 4-20mA/1-5V/2-10V input signal
- Self-calibrating with continuously output position monitoring signal as standard
- Mechanical over torque protection optional
- Watertight IP67 and NEMA 4X aluminum alloy enclosure with 100% underwater tests
- World-leading EMC, 100% passed EFT, ESD and Surge tests
- Stable operation on extra high/low temperature with high humidity
- Hard die cast aluminum alloy enclosure with powered coated to resistance corrosion
- All metal gear train with self-locking worm gear
- CSA listed/UL complied/CE marked/RoHS 3.0 tested
- Visual valve position indicator
DCL small size modulating type electric actuators are widely used in combustion system, especially for burners, both in China and USA. Actuators are installed on the fuel intake duct/pipe to control flame or installed on ventilation valve to control temperature. Since the boiler is always in very high temperature and always has strong electromagnetic interference to surroundings, so the actuator must suffer very severe applications.
Though the controller is very small, but its electric clearance creep distance satisfies the UL standard. It can suffer 2500V surge test, 4000V EFT test, 4000V ESD test to ensure world leading EMC performance. Moreover, it also passed 85/85 test, which is continuously working in 85℃ and 85% humidity for over 600 hours. So it serves top 2 air conditioning companies ,Gree and Midea, in China, and also some top world famous brands such as McQuay, Danfoss, Dunham-bush etc.
|Actuator Type||Standard Time/Torque||Optional Time/Torque||Turning Angle(Max.range)||Total Weight||Power Supply||Selected Control Circuit|
|DCL-02||15S/18Nm||7S/9Nm 60S/18Nm||0~90°Adjustable||1.2Kg||DC24V/AC24V AV110V/AC220V||Types of A/B/E/G|
|DCL-05||20S/50Nm||4S/20Nm 10S/30Nm 60S/50Nm||0~360°Adjustable||2.5Kg||DC24V/AC24V AV110V/AC220V/AC380V||Types of A/B/C/D/E/F/G/H|
|DCL-10||30S/100Nm||15S/50Nm 60S/100Nm||0~360°Adjustable||4.5Kg||DC24V/AC24V AV110V/AC220V/AC380V||Types of A/B/C/D/E/F/G/H|
|DCL-20||30S/200Nm||15S/100Nm 60S/200Nm||0~90°Adjustable||9Kg||DC24V/AC24V AV110V/AC220V/AC380V||Types of A/B/C/D/E/F/G/H|
|DCL-100||30S/1000Nm||15S/500Nm||0~90°Adjustable||19Kg||AV110V/AC220V/AC380V||Types of A/B/C/D/E/F/H|
|Performance Parameters List of Adjusting type(Type E)|
