CSA 90° DC24V Turn ExdIICT4 150Nm Explosion Proof Actuator

  • CSA 90° DC24V Turn ExdIICT4 150Nm Explosion Proof Actuator
Place of Origin WUHAN,CHINA
Brand Name DCL
Certification CE/ROHS/CSA/IP68/IECEx/ATEX/UL
Model Number All explosion proof electric actuator
Minimum Order Quantity 1pc
Packaging Details carton/pallet
Delivery Time 7 working days
Payment Terms D/P,T/T,Western Union,MoneyGram
Supply Ability 2000PCS/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Standard Torque 50Nm To 600Nm Standard Time 20s To 45s
Power Supply 24VAC/110VAV/220VAC/380VAC/24VDC Motor Power 6W To 90W
Protection Grade IP68 NEMA 4X Total Weight 3kg To 10kg
Ambient Temperature -25℃~+55℃ / -13°F~+131°F Installation Angle 360°
Highlight

CSA explosion proof actuator

,

90° turn explosion proof actuator

,

DC24V explosion proof actuator 150Nm
Leave a Message
Product Description
90° Turn ExdIICT4 Explosion Proof Electric Actuator, CSA certified 50Nm-600Nm
Features
  • Quarter turn with proportional to input control signal, mechanical limits
  • Auto-calibrating with continuously output position monitoring signal as standard
  • Multi input signal switchable in one smart control pack
  • Watertight IP67 and NEMA 4X aluminum alloy enclosure with 100% underwater tests
  • Fully potted resin plastic packaged controller resistance to vibration and moisture
  • Stable operation on extra high/low temperature with high humidity
  • All metal gears with self-locking worm gear
  • CSA listed/UL complied/CE marked/RoHS 3.0 tested
Description

The enclosures of DCL explosion-proof electric actuators are manufactured using higher-tonnage die-casting machines compared with standard actuator series, ensuring a denser structure with no micro-pores. The housing walls are intentionally made thicker to withstand any internal gas explosion pressure. The quality of the cylinder-stop mating surface is critical for ensuring flameproof integrity—scratches, dimensional errors, insufficient stop length, rust, or cracks are strictly prohibited. Therefore, every enclosure undergoes 100% inspection by DCL upon arrival from suppliers.

The actuators have been officially tested by CSA and comply with ATEX, UL, and CSA standards, enabling their use in multiple global markets, including Europe, North America, and other regions requiring certified explosion-proof equipment.

Specification
Actuator Type Standard Time/Torque Optional Time/Torque Turning Angle(Max.range) Total Weight Power Supply Selected Control Circuit
DCL-Ex05 20S/50Nm 4S/20Nm 10S/30Nm 60S/50Nm 0~360°Adjustable 3.0Kg DC24V/AC24V AV110V/AC220V/AC380V Types of A/B/C/D/E/F/G/H
DCL-Ex10 30S/100Nm 15S/50Nm 60S/100Nm 0~90°Adjustable 5.0Kg DC24V/AC24V AV110V/AC220V/AC380V Types of A/B/C/D/E/F/G/H
DCL-Ex20 30S/200Nm 15S/100Nm 60S/200Nm 0~90°Adjustable 5.5Kg DC24V/AV110V/AC220V/AC380V Types of A/B/C/D/E/F/G/H
DCL-Ex40 30S/400Nm 15S/200Nm 60S/400Nm 0~90°Adjustable 9.5Kg DC24V/AV110V/AC220V/AC380V Types of A/B/C/D/E/F/G/H
DCL-Ex60 45S/600Nm
0~90°Adjustable 10Kg DC24V/AV110V/AC220V/AC380V Types of A/B/C/D/E/F/G/H
Actuator Type Butterfly Valve(≤PN1.0MPa) Ball Valve(≤PN1.6MPa) Vent Valve(≤PN0.1MPa)
DCL-Ex05 DN50~65 DN40 DN50~80
DCL-Ex10 DN80~100 DN50~65 DN100~200
DCL-Ex20 DN125~150 DN80~100 DN250~300
DCL-Ex40 DN200 DN125 DN350~450
DCL-Ex60 DN250 DN150 DN500~600
