Low Temperature Rise 400Nm IP68 DC Rotary Actuator
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Action Time | 15S/30S | Type | Compact Actuator |
|---|---|---|---|
| Power Supply | 24VDC | Name | DC Rotary Actuator |
| Feature | Watertight | Protection Grade | IP68 |
| High Light | IP68 DC rotary actuator,24V DC rotary actuator |
||
Product Description
Compact watertight DC rotary actuator with protection against dust and water / IP68
Specification:
| Action Time: | 15S/30S |
| Input Signal: | 4-20mADC |
| Output Signal: | 4-20mADC |
| Name: | DC Rotary Actuator |
| Installation Angle: | 360° |
| Total Weight: | 4.5KG/9.5KG |
| Protection Grade: | IP68 NEMA4/4X |
| Output Torque: | 0~400Nm |
| Type: | Compact Actuator |
| Power Supply: | 24VDC |
| Feature: | Watertight |
| Motor Power: | 30W/70W |
| Ambient Temperature: | -25℃~+55℃ / -13°F~+131°F |
Features
- Quarter turn operation modulated by 24VDC power
- Torque can be precisely setting within a certain range
- Heavy duty DC brushless motor with low temperature rise during production
- Compact smart resin plastic packaged drive controller
- Stable operation on extra high/low temperature with high humidity
- Weatherproof IP 67 robust aluminum alloy enclosure with powder coated
- All metal gears with self-locking worm gear
- UL standard/CSA listed/CE marked/RoHS 3 complied
Description
DCL compact electric actuators are most commonly used in HVAC field with butterfly valve. In many building automation systems, electric actuators are widely used to control indoor temperature, air conditioner air volume, water flow, condensate flow and hydraulic balance etc.
DCL use heavy duty motor with 80% duty rate that can do more frequently control to make temperature more accuracy. Very long operation life makes after sell maintenance become easy and cost saving. Also, it can be installed indoor or outdoor with resistance to severe environment. Dehumidify heater is optional to help protect actuator against damage caused by condensation. All HVAC used electric actuator are tested to rigorous UL and CSA standards and certified by CSA and CE & RoHS tested by SGS.
