WCB Electric Actuated Ball Valve
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| High Light | WCB Electric Actuated Ball Valve,DN100 Electric Actuated Ball Valve |
||
|---|---|---|---|
Product Description
3-piece high performance metal seal electric actuated ball valve / abrasive fluids use
Specification
| Actuator Type | Butterfly Valve(≤PN1.0MPa) | Ball Valve(≤PN1.6MPa) | Vent Valve(≤PN0.1MPa) |
| DCL-Ex05 | DN50~65 | DN40 | DN50~80 |
| DCL-Ex10 | DN80~100 | DN50~65 | DN100~200 |
| DCL-Ex20 | DN125~150 | DN80~100 | DN250~300 |
| DCL-Ex40 | DN200 | DN125 | DN350~450 |
| DCL-Ex60 | DN250 | DN150 | DN500~600 |
Features
Ball valve
- 3-piece high performance design
- Size from DN15 to DN100, 1/2” to 2”
- WCB and CF8M body available
- Threaded type, socket type and butt type optional
- Unidirectional (FMU) or bidirectional (FMB) shutoff options available.
- Oversized stem design prevents deformation at higher pressures and temperatures
- Larger ball design provides better sealing to prevent leakage
- Live-loaded packing design
- Dual anti-static devices provide longer life cycle
- Blowout proof stem
- ISO 5211 mounting pad
Electric actuator
- 90° operation, middle position optional
- All 40Cr alloy spur gears, hard copper alloy worm gear, metal tapered roller bearings
- Permanent lubricated without maintenance for over 10000 full range life cycles
- Corrosion protection aluminum alloy housing with thermally bonded polyester coating
- Heavy duty motor with thermal overload protection
- Allen wrench manual override/handwheel optional
- Flat or dome indicator for valve position
- ISO5211 multi flange mounting
- CSA certified per UL standard/CE marked
Description
DCL metal seat electric ball valves are designed for severe applications such as high temperature, high pressure, and abrasive fluids found in Oil & Gas, Petroleum, Petrochemical, Chemical, Power Generation, Pulp & Paper, and Mining industries.
